静電容量方式タッチセンサー

Touch sensitive sensor

Thin touch sensor using transparent conductive polymer
  • mobility
  • electronics
Design improvements HMI functionality improvements
Product category Design/COmfortable

Touch sensitive sensor

Realization of safe and smooth HMI devices

In order to achieve automated driving, a number of systems, such as advanced driver assistance systems (ADAS) and infotainment systems, are needed on-board. Furthermore, human-machine interface (HMI) design will be increasingly important for drivers to understand and operate those systems correctly and safely.
For example, when the driver needs to intervene in case of an emergency, a sensor system is required to detect the driver’s operation accurately, while immediately informing the driver and assisting the safe and smooth operation of the vehicle. In addition, the design of the interior and HMI must be consistent, which requires sensors with a high degree of design flexibility.

安全でスムーズなHMIデバイスの実現

Thin touch sensor for 3D shapes

SEKISUI’s touch sensitive sensor is a thin film-based touch sensor.

The use of flexible polymer-based material makes it suitable for installation on bent or curved surfaces, and it can be used for a variety of input methods, including touch, slider, and wheel types.
Screen-printed designs and 3D shaping are also supported, contributing to next-generation HMI and interior design.

3D形状にも対応する薄型タッチセンサー

Technical information

Technical information

Technical overview

 Thin design

Film-based electrostatic sensor

All made of flexible polymer-based material.
Ideal for bending and curved surface application.
薄型化

 Various input operations

Touch, slide, wheel, multi-touch

On top of On/Off, position, movement amount, movement direction, rotation direction, and coordinates can be detected.
多彩な入力操作

 High reliability

Excellent keytouch durability and weather resistance

No degradation from keystrokes. Weatherability and sulfurization resistance to meet stringentautomotive specifications.
高信頼性

 Scalability (3D, material lamination design)

Variation of design

Illuminated, screen-printed designs, 3D shapes, seamless, and material laminated design.
拡張性(3D化、意匠素材積層)

Technical details

 Thin design

The 0.1 mm film base allows installation in narrow gaps.

 Various input operations

Switch
Slider
Wheel
Touchpad

 High reliabilityHigh reliability for automotive applications

Testing time (h)
Sulfurization resistance test S-gas5.6ppm,
85°C×288h

 Scalability (3D, design material stacking)

Functions and designs can be expanded through the addition of screen printing
processes, 3D shapes, and lamination with design materials.
